Description:

The sister car to our original very successful Gold Leaf Team colours Caterham Blackbird, and only for sale due to a change in team plans.

Built from  championship winning  Supergrad S3,  chassis professionally converted and refurbished by Arch Motors.

Since build completion in 2019 has had very limited use - comprising  a total of 2 test sessions and 2 race meetings.

Chassis History

2001 - Originally built  as a 1600 K series Super Graduate - (imperial bronze welded chassis).

2013 -  Won Megagraduates Championship.

2017 -2019  Conversion to  Honda Blackbird race specification.

Upgrades from Caterhams original Blackbird Specification

• Carbon nosecone
• Carbon front & rear wings
• Lowered drivers floor
• Kevlar sheet protection to drivers floor
• Full Aluminium tonneau cover
• Aluminium drivers door

Engine & Drivetrain

• Honda CBR 100 XX Blackbird  engine - 1137cc
• Gas flowed and ported cylinder head
• Race camshafts
• Mikuni Carburettors
• Nova Dry Sump system
• Pace dry sump tank and scavenge pump
• Nova billet aluminium reversing gearbox
• Nova C/R 6 speed gearset
• Bespoke carbon side entry airbox with K & N filter
• 4-2-1 St/St exhaust system
• RaceCo exhaust silencer - repackable (new packing)
• 3.38:1 Limited Slip diff by Road & Race

Engine stripped, inspected and rebuilt by BIg CC Racing using all new parts as necessary before installation.

Build Specification

• Wide track front suspension
• Bilstein Race dampers
• Powerflex bushes fitted throughout
• 22% Quick steering rack
• Aluminium Race radiator
• Setrab 15 row oil cooler
• Front & adjustable rear anti roll bars
• Race Master cylinder
• Tilton adjustable brake balancer
• Lightweight Li-Ion Battery
• Moulded resin seat
• TRS Pro ultralite 6 point harness - in date
• Q/R  Momo wheel
• Zero 360 2.25Kg  Fully plumbed mechanical fire system (bottle will have current inspection at sale)
• My Laps Transponder - wired in to loom.
• Digital Speedo (Code 60)
• Racetech  mechanical oil pressure/oil temperature  guage
• Racetech Water temperature guage
• CBR 1100  Rev counter
• Carbon F1 race mirrors
• Daytime running lights and High Intensity rear rain light

Supplied with:

• 2 sets 13" Caterham Orcus alloys - 6" dia fronts & 8" dia rears
• 1 set 13" Caterham compomotive alloys
• 1 set  Avon ZZS tyres
• 1 set Avon CR 28 sport wet tyres

Car weighs in at 460 Kgs (dry) and is ready for competition.

All  build receipts and original Caterham history available.
