Description:

• 450Nm (330lbf ft) maximum input torque capacity*
• 6 speeds with sequential gearchange selection
• Dog clutch non-synchromesh gear engagement for 6 forward gears. Sliding mainshaft reverse gear
• Pneumatic Assisted Gearchange System (AGS) operated by Xtrac and MegaLine’s new P1254 Integrated Valve Actuator (IVA)
• Aluminium L169 castings, with ‘O’-Ring face sealing
• Lubrication via single stage eccentric lobe pump, configured for use with an external cooler
• Differential is an Xtrac cassette type plate unit with a choice of ramp angles, plate and preload settings. Quick change diff cassette is easy to remove and positive preload can be adjusted externally
• Left hand output flange is integral with the differential, to suit GI 82 size tripode joint or Lobro style CV joint
• Suitable for use with AP Racing CP6859 family of clutch release cylinders
• Gearbox weight is approximately 35kg (77lb)*
• Gear ratio：
• 1st:  13/35  2nd:14:30  3rd:14:24  4th:17/24  5th:16/21 6th:26/25  r:13/42
